Heras fencing is a strong protection system used to secure and define construction and building sites, to avoid infiltration operations inside the sites. There are different measurements for Heras fencing that differ according to the purpose of use. Therefore, it is important to know the standard heras fencing size. To know the most important dimensions and measurements of the fence, read the following.
Standard measurements for Heras panels in construction sites
Using the standard heras fencing size in construction sites is of great importance, due to providing speed in installation and planning. Also, they are transportable and usable, which makes them ideal for temporary sites. The standard scale in it is as follows:
- Height: 2 metres.
- Width: 3.5 metres.
- Horizontal tube: 25.4 mm.
- Vertical tube: 38.1 mm.
- Round frame: 38.1 mm.
- Finish: Galvanised wires.
Dimensions of Heras fencing commonly used in securing areas
The dimensions of Heras fencing commonly used in securing areas come as follows:
- Height: 2 metres.
- Width: 2.5 metres.
- Mesh opening height: 250 mm.
- Mesh opening width: 100 mm.
- Weight: 12.5 kg.
- Grid bars: Welded steel.
The difference between the measurements of standard Heras models
The differences in the heras fencing size for various models appear as follows:
Round top panel vertically reinforced
- Fixing panel: 2 metres x 3.5 metres.
- Frame tube: 1.5 mm x 38 mm.
- Mesh width: 100 mm x 262 mm.
- Horizontal wire: 3.2 mm.
- Vertical wire: 2.2 mm.
Anti-climb round top panel horizontally fixed
- Fixing panel: 2 metres x 3.5 metres.
- Frame tube: 1.5 mm x 38 mm.
- Reinforcement tube: 38 mm.
- Mesh width: 43 x 262 mm.
- Horizontal wire: 3.2 mm.
- Vertical wire: 2.2 mm.
Anti-climb square top panel vertically fixed
- Fixing panel: 2 metres x 3.5 metres.
- Vertical frame tube: 1.5 mm x 38 mm.
- Horizontal frame tube: 1.2 mm x 30 mm.
- Mesh width: 43 x 262 mm.
- Horizontal wire: 3.2 mm.
- Vertical wire: 2.2 mm.
Heavy-duty square top panel
- Fixing panel: 2 metres x 3.5 metres.
- Vertical frame tube: 1.5 mm x 38 mm.
- Horizontal frame tube: 1.2 x 30 mm.
- Mesh width: 100 x 262 mm.
- Horizontal wire: 3.2 mm.
- Vertical wire: 3.2 mm.
Who is the best company?
Arab Metal Fences Industry is considered one of the best manufacturing companies for metal fences called Heras fencing, due to the following:
- Providing multiple types of fences that suit different uses, such as acoustic Heras fencing and anti-climb Heras fencing.
- The quality of used materials, as it is manufactured from galvanised wires and steel pipes.
- Ease in installing panels and posts, as well as in periodic maintenance operations.
- Its products have light weight and are resistant to different weather factors.
- Availability of different types of the standard heras fencing size, where fence panels vary to suit different working conditions.
Conclusion
The standard heras fencing size is the best measurement to apply effective protection and better organisation of construction sites. The most common scale is 2 metres height and 3.5 metres width, which is what the Arab Metal Fences Industry uses to meet safety standards.
FAQs
How big is a standard fence?
The volume of the standard heras size suitable for use in many sites is 2 metres x 3.5 metres.
Why is it called Heras fencing?
It is called Heras fencing after the Dutch company Heras, which invented this type of metal fence.
